1 Line Diagram with Short Circuit or Fault Current Calculation

First ever automatic graphic 1 Line Diagram.

Its Purpose:

Construction documents for projects require the 1 Line Diagram. PowerCalc brings you the 1st ever 1 Line Diagram that’s automatic, graphic and simultaneously generated throughout the design process. Our patented technology calculates all the values for the 1 Line Diagram with our 7+ million equations. And now, these electrical engineering values are also visual in real time. PowerCalc makes electrical engineering design so easy!

These values indicate the information supporting the design’s intent and confirm a balanced and protected power distribution system including: short circuit current, system grounding arrangement, voltage hierarchy and connection to the grid.

New Construction

In new construction, the entire power distribution system must be summarized in either a 1 Line Diagram or Riser Diagram. The 1 Line Diagram is preferred and shows the horizontal relations between the different components of the power distribution system. The Riser Diagram shows the vertical relations.

Renovation

In renovation, the 1 Line Diagram is the starting point to determine the project’s impact on the existing power distribution system. The designer analyzes the ampacity, capacity, AFC and fault current. PowerCalc quickly accomplishes this analysis providing the information necessary to make sound engineering decisions for a cost effective design.

OSHA

OSHA now requires the 1-Line Diagram to be generated and posted in all commercial buildings. General Duty Clause, Section 5(a)(1) of OSHA 1970 (120.1 and 205.2) referencing NFPA 70E.

1 Line Diagram: The Holy Grail of Electrical Engineering.

Background Information:

Get ready for the first ever fully automatic, graphic 1 Line Diagram.

Within a few weeks, PowerCalc will publish its latest application: the 1 Line Diagram.

This isn’t just any 1 Line Diagram, this one is completely integrated with PowerCalc’s 7 million+ equations. It’s not just an isolated one-off calculation.

PowerCalc already provides all the values for the 1 Line Diagram, but now it will also graphically display and build your 1 Line Diagram automatically and simultaneouslythroughout the design process. And the 1 Line Diagram is always there for the User to see, analyze and revise.

We all know that a picture is worth a thousand words, but up until now, for electricals this has not been possible until the end of the design process and after days spent designing. The 1 Line Diagram has been a one-off, after-the-fact exercise put together at the end of a project usually with a separate application.

But now, the User can view the 1 Line Diagram throughout the design process on a separate screen or using a split screen. And, if you don’t like that generator in the west wing of St. Mary’s Hospital, just drag that box to the East Wing. All the calculations follow. That’s what 7 million+ equations can do for you.

Just to let everyone know, the 1 Line Diagram is a simplified notation for representing a 3 –phase power system. It is required to be posted in all commercial buildings and also required for building permits. Electrical elements such as circuit breakers, transformers, capacitators, bus bars and conductors are indicated with standard symbols. This block diagram indicates the flow of power between the electrical elements and usually parallels the same sequence as the switchgear or other equipment represented (left-to-right or top-to-bottom). The illustration above, indicates these graphics using Schneider equipment.

The values on the 1 Line Diagram indicate the information supporting the electrical engineering design’s intent and confirms a balanced and protected power distribution system including: short circuit current, system arrangement, voltage hierarchy and connection to the grid. It confirms theory: when the 3 phases of a 3 phase power system are balanced, then each phase can be considered separately.

PowerCalc Automates the Electrical Design Process:

It is well established that automation is the driver in our techcentric society and business world.

Automation drives productivity across all businesses large or small. Changes, even small ones, over time snowball into massive gains in productivity.

It includes: automation of processes with databases, standards, and updated procedures resulting in fewer errors, fewer building department comments, fewer issues with finished designs and less downtime during construction. And, just less time spent on design and repetitive calculations.

To illustrate this point, we've put together the chart shown that focuses on design time. It shows how PowerCalc streamlines the design process to save days of engineering man hours. Save Time/Save Money.

Let me know what you think…we’ll keep you posted on our launch of the 1 Line Diagram application. In our next issue, we’ll talk more about why PowerCalc won gold for Consulting Specifying Engineer’s “2016 Product of the Year”.

More information on 1 Line Diagram: Holy Grail of Electrical Engineering.

1 Line Diagram Development.

Video Insight:

 Taking you behind the scenes at PowerCalc, we’re putting together a mini-series about our people and all the things we do.

As part of the development of the 1 Line Diagram, Dave, Jessica and James work together consistently for the launch later this month.

Please enjoy an update on the development process of this revolutionary tool.

more information on the 1 Line Diagram Development process.

Incredible 1 Line Diagram.

Video Insight:

To update you on the development of our 1 Line Diagram application, we've put together our video to give you a glimpse at it in action. PowerCalc's  incredible 1 Line  is  automatically and simultaneously generated with each input throughout the design of the power distribution system.

As part of the development of the 1 Line Diagram, Dave, Jessica and James discuss finalizing its details and testing for launch in the near future.

More information on the Incredible 1 Line Diagram.

1 Line Diagram Ready for Launch.

Video Insight:

 We're set to launch the 1 Line Diagram this month, January 2018.  We've put together a video to give you a glimpse of it in action. PowerCalc's  incredible 1 Line  is  automatically and simultaneously generated with each input throughout the design of the power distribution system.  It is design magic and a first in every way.

As part of the development of the 1 Line Diagram, Dave, Jessica and James discuss finalizing its details and testing for launch in the near future.

More information on the 1 Line Diagram Ready for Launch.

The Incredible 1 Line Diagram Ready is Here!

Video Insight: This Revolutionary Tool's Launch

Its Launch Day and we are proud to announce the 1st ever automatic, graphic and simultaneously generated 1 Line Diagram. You talked, we listened...and the result is the one and only real time 1 Line Diagram on the planet.

Our patented technology calculates all the values for the 1 Line Diagram with our 7+ million equations. And now, these electrical engineering values are also visual. PowerCalc makes electrical engineering design so easy!

We have a brief introduction for you.

We all know that a picture is worth a thousand words, but up until now, for electrical professionals seeing the 1 Line Diagram has not been possible until the end of the design process and after days, weeks and months spent designing. The 1 Line Diagram has been a one-off, after the fact exercise at the end of the project put together using a separate application.
